Product Detail
Product Tags
| BRAND & MODLE |
| KOS |
KOS-2000E |
KOS-2000P |
| PV INPUT |
| ADAPTER INPUT POWER |
550W |
800W |
| START VOLTAGE |
16Vdc |
| WORK VOLTAGE RANGE |
12-60Vdc |
| MAX. INPUT CURRENT |
16A |
| MPPT TRACKING EFFICIENCY |
99% (Static State) |
| AC INPUT |
| MAX. CHARGING POWER |
1000W |
1100W |
| INPUT VOLTAGE RANGE |
150-276V |
| MAX. INPUT CURRENT |
5A |
6A |
| INPUT TERMINAL |
C14 Plug×1 |
| AC OUTPUT |
| RATED OUTPUT POWER |
1000W |
1200W |
| OUTPUT VOLTAGE RANGE |
230Vac±10%, BY-PASS 230V±10% |
| NOMINAL FREQUENCY/RANGE(Hz) |
50/45-55 Hz or 60/55-65Hz (Depends on country difference) |
| RATED OUTPUT CURRENT |
4.35A |
5.5A |
| OUTPUT TERMINAL |
Universal Socket*2 |
| DC OUTPUT |
| USB Type-A×2 |
5V/2A, 2 Pannel, Max. output of 1 panel is 10W |
| USB Type C×1 |
5V/2A, 10W Max each |
| CELL DATA |
| CELL TYPE |
Double LFP CELL (314Ah) |
| RATED CAPACITY |
2009.6Wh |
| CELL LIFETIME |
6000 cycles @ 90% DoD |
| NOMINAL CELL VOLTAGE |
3.2V*2 |
| OTHER DATA |
| WEIGHT |
≈18kg |
| SIZE |
420×400×92mm (Hand-measuring, small gap is possible) |
| COLOR |
DARK BLACK/WHITE |
| COOLING SOLUTION |
Forced-air |
| IP LEVEL |
IP20 |
| PROTECTION FUNCTION |
Short-circuit, overcurrent, overvoltage, over-temperature, PV input reverse connection, battery overcharge and overdischarge, high and low temperature protection for battery cells, etc |
| WORKING TEMPERATURE |
| TEMPERATURE RANGE |
-40℃-60℃ |
| ENVIRONMENT ALTITUDE |
≤3000m (go over the top) |
| ENVIRONMENT HUMIDITY RANGE |
10%-90% |
